This is a standard Tomix manual point that resembles a synthetic resin sleeper that is 140 mm long and branches off at 15 to the left with a curve radius of 541 mm.

Features

• Fully selective, can be used as a spring point
• When combined with C541-15 rail, it branches to 37mm double track spacing
• When two rails are used, a single crossover track with 37mm double track spacing at a distance of 280mm is achieved
• Gaps are achieved by exchanging it with a gap joiner sold separately
• Fully selective, with +/- current to both rails being completely switched, allowing for simple electrical wiring even in reverse operation and complex point installation
• Can be converted into an electric point with one separately sold Point N drive unit, and operates by combining Point Control Box N and Power Unit N
• Dummy point motor included
• Durable die-cast molded tip rails
• Synthetic sleeper representation, ballast and sleepers are painted for a beautiful appearance
• Rails are joined with claws for a simple and reliable connection
• Improved joiner is used for the joiner
• Connection compatible with conventional Tomix rails
