On the inside of a 45 degree curve with a radius of 317 mm, the N-CPR317/280-45(F) branches to the right, while the N-CPL317/280-45(F) branches to the left, at a radius of 280 mm and 45 degrees. It is a fully selective type and can also be used as a spring point.

Features

• Compatible with conventional Tomix rails
• Rails are joined with claws
• Improved joiners are used for the joiners
• Operates in combination with Point Control Box N and Power Unit N
• One Finetrack point N drive unit is built into the trackbed
• The +/- current of the two rails can be completely switched in two directions using two built-in contacts on both rails, allowing for simple electrical wiring even in reverse operation or when installing complex points
• When combined with two existing C317-45 curved rails or two C280-45 rails, it branches to a double track spacing of 37 mm in a 90 degree curve section
• A single crossover track with a double track spacing of 37 mm in a 90 degree curve section can be achieved by combining one N-CPR317/280-45(F) and one N-CPL317/280-45(F)
• Gaps can be achieved by replacing the track with an insulated joiner (sold separately)
• Includes dummy point motor, spring point sign, manual switch, sign stickers, etc.

Specification

• Electric points N-CPR317/280-45(F)(Fully selectable)
